60 Inch Multi Touch Infrared Touch Frame Overlay ROHS Certification

Basic Information
Place of Origin: China
Brand Name: YCLTOUCH
Certification: RoHS, ISO 9001:2000, ce, EMC, LVD
Model Number: LV-60
Minimum Order Quantity: 1
Price: Negotiable
Delivery Time: 3-7 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20000/month
Size: 60 Inch Ratio: 16:10
Touch Times: Infinite Time Glass: 4mm Glass Or No Glass
Brand Name: YCLTOUCH Material: Aluminum
High Light:

60 Inch Multi Touch Infrared Touch Frame


Multi Touch Infrared Touch Frame ROHS


60 Inch Touch Screen Overlay

60 Inch multi-touch infrared touch frame infrared touch screen overlay


Infrared / IR Touch Frame

A matrix of Infrared (IR) LEDs and photo diodes are used to create a two dimensional grid over the display to detect where infrared light is blocked and thus where touchpoints are. YCLTOUCH' s available in both standard and custom industrial infrared touch screen sizes, YCLTOUCH’s projected custom infrared touch screen forms, fit or function replacements for 3M™ and Elo™ touch sensors.


IR Touch Frame Technology

IR touch screen frame technology may not be new, but it remains a favorite. It tends to be employed in large-format displays and some kiosks and point-of-sale (POS) terminals. The custom touch screen display has a long life, furthering its popularity in the digital signage and interactive display markets.


How IR touch frame Red Works:

Infrared touch technology requires a perimeter to be placed around the infrared touch screen. The perimeter consists of infrared LEDs placed on two sides of the IR touch frame and phototransistors placed on the opposing two sides. The two sides then work in pairs; the signal from the LED transistor is read by its opposing phototransistor. When that signal is interrupted, it indicates a blocked infrared beam, which, in turn, indicates a touch point. While most infrared custom touch screen display doesn’t require a touchscreen, a glass overlay usually is recommended in order to protect the underlying display.

60 Inch Multi Touch Infrared Touch Frame Overlay ROHS Certification 0

Infrared touch screen Features:


1 Anti-light, sunshine from any angle does not affect touch control

2 True 10-point touch, touch experience is not affected by object occlusion

3 Strong anti-jamming ability, anti-static performance of industrial ESD

4 Hardware design of industrial control level, working normally at 15℃~55℃

5 Strong compatibility, drive-free support for multiple operating systems

6 Provide self-developed touch screen configuration software and remote assistance tools

7 Support gesture function, customize output protocol, interface and application development

8 Response fast, sensor discontinuous damage 10%, can still work

9 The size can be customized




Ratio: 16:9

Number of Touch Points: 20

Minimum Touch Object: 4mm

Touch Activation Force: No minimum touch pressure required

Touch Durability: Unlimited

Driver Free: HID compatible, up to 20 touch points

Linearity Deviation: ±1mm

Frames per Second: Up to 50 fps

Fault Tolerance: Workable even 75% sensors are damaged

Typical Response Time: -10ms

Operating Systems: Windows7,Windows8,Windows10,MacOS,Linux,Android

Light Transmission: 100% without glass

Protocols: HID,TUIO,Flash


Operating Temperature: -0°C to 70°C

Storage Temperature: -0°C to 85°C

Operating Humidity: 10% to 90%RH(Non-condensing)

Storage Humidity: 10% to 90%RH

Certification: FCC,CE,ROHS

Warranty: 1 year


  • Gaming / casino systems
  • Outdoor and indoor kiosks
  • Entertainment
  • Transport and ticketing
  • Hospitality
  • Banking
  • Сustomized solutions


60 Inch Multi Touch Infrared Touch Frame Overlay ROHS Certification 1


60 Inch Multi Touch Infrared Touch Frame Overlay ROHS Certification 2 60 Inch Multi Touch Infrared Touch Frame Overlay ROHS Certification 3



60 Inch Multi Touch Infrared Touch Frame Overlay ROHS Certification 4


Transportation and Payment

60 Inch Multi Touch Infrared Touch Frame Overlay ROHS Certification 5


60 Inch Multi Touch Infrared Touch Frame Overlay ROHS Certification 6
